~ 300 - 310 $
Brand
Model year
2021

BODY MATERIAL: ALUMINIUM + CI4+
SPOOL MATERIAL: COLD FORGED ALU (TI COATED SPOOL RING)
WATERPROOF DRAG: YES
HANDLE: SCREW IN MACHINED ALU SINGLE HANDLE
OSCILLATION: AERO WRAP

  • HAGANE GEAR
  • X SHIP
  • G FREE BODY
  • ARC SPOOL
  • S ARB
  • ONE PEICE BAIL
  • X PROTECT
  • HAGANE BODY
  • RIGID SUPPORT DRAG
  • MGL ROTOR
  • CI4+
  • LONG STROKE SPOOL
  • MICROMODULE II
  • SILENT DRIVE

Sustain FJ key features:

S A-RB

S A-RB

Shielded Stainless Steel Anti-Rust Bearings. These bearings have undergone a special heat treatment resulting in high metal strength. Shielded A-RB bearings use either a rubber shield or stainless steel shield (depending on bearing size) for the ultimate in corrosion resistance and contaminant protection against sand, salt or dust.

X-SHIP

X-SHIP

X-Ship provides improved gear durability. By supporting the pinion gear on both ends with bearings, the pinion gear maintains precise alignment with the drive gear. This allows the gears to stay in the same position under the heaviest loads. The added benefit of X-Ship technology is that friction between the spool shaft and gear are eliminated. This further benefits anglers with enhanced casting performance and casting distance of lighter lures.

HAGANE

HAGANE

Hagane is a Shimano reel design concept created to withstand continual use and extreme abuse. Hagane is an innovation with built-in toughness and durability that works alongside Shimano's precision engineering.

HAGANE GEAR

HAGANE GEAR

With amazing strength and durability, the HAGANE Gear is at the very heart of most Shimano reels. Shimano, through the application of state-of-the-art technologies, gives anglers the long-lasting smoothness and pleasure that is felt when anglers first use a reel, over and over again. No cutting work is applied to the teeth of the drive gear during fabrication, instead the entire surface is calculated in minute detail by special 3D-design and then formed by Shimano's cold-forging technology.

HAGANE BODY

HAGANE BODY

The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminates body flexing on the reel while fighting fish. The result transforms the angler's actions directly into cranking power, increasing efficiency through strength.

SILENT DRIVE

SILENT DRIVE

SilentDrive technology benefits from a total redesign of all functional parts focused on the drive gear, worm shaft and other parts. The goal: remove unnecessary noise and vibration. In doing so, the overall tolerances are improved to a micron level, ultimately creating an overall quieter and smoother reel operation.

RIGID SUPPORT DRAG

RIGID SUPPORT DRAG

By strengthening the spool support of the main shaft, the play and fluctuation of the spool during drag operation are suppressed. The Rigid Support Drag allows smooth and consistent drag delivery, even under high load.

AR-C SPOOL

AR-C SPOOL

The spool has a special spool ring shape. This creates a rectifying effect on the line and realizes both suppression of line trouble and long casting performance.

ONE-PIECE BAIL

ONE-PIECE BAIL

One-Piece Bail allows the line to travel unimpeded to the line roller. The seamless design reduces friction and decreases the chance of tangles or the line catching on the bail arm.

MICROMODULE GEAR II

MICROMODULE II

Shimano's exclusive manufacturing technology further advances MicroModule Gear II with a state-of-the-art gear-tooth surface design. The surfaces of the drive gear and pinion gear have been analyzed and updated from the ground up in Shimano’s pursuit of perfection to further improve the smooth gear feeling and reducing sound.

LONG STROKE SPOOL

LONG STROKE SPOOL

The Long Stroke Spool has a longer stroke compared to conventional spool designs. This ultimately produces a smoother line lay during retrieval and translates into increased casting distance for anglers.

CI4+

CI4+

CI4 is a Shimano original material reinforced with carbon fiber that is lighter and has a higher strength than conventional resin material. CI4+ is an advanced version of the original CI4 material and is 2.5x more rigid than its predecessor. While improving lightness and rigidity, reel bodies and rotors built with CI4+ are further reduced in size and weight.

X-PROTECT

X-PROTECT

For medium and small general-purpose spinning reels, which require lighter spinning, we focused on a non-contact structure that does not compromise the lightness of the spinning. In addition to conventional water-repellent treatment, a labyrinth structure that suppresses water penetration is combined to achieve high water-resistant performance despite the non-contact nature of the structure. It is used in the stopper bearing section and line roller section.

G-FREE BODY

G-FREE BODY

G-Free Body technology has been developed to shift the reel's center of gravity closer to the rod. By moving the center of gravity closer to the angler’s hand, the G-Free Body helps to reduce fatigue and enhance casting comfort.


Sustain FJ lineup:


Sustain FJ specification:

Model Size Bearings Gear ratio Weight Drag power Line per cranck Line capacity Handle position Approx. Price
21 Sustain FJ 2500 2500 8+1 5.3:1 210.00 GM / 7.40 OZ 9.00 KG / 20.00 LB 78.00 CM / 31.00 IN Mono (#TEST/YD): 6/200, 8/140, 10/120 | Braid (LB/YDS): 10/150, 15/145, 30/100 | Mono/Braid (MM/M): 0.18-290/0.20-240/0.25-160 Left hand, Right hand ~ 300 $
21 Sustain FJ 2500HG 2500 8+1 6.0:1 210.00 GM / 7.40 OZ 9.00 KG / 20.00 LB 89.00 CM / 35.00 IN Mono (#TEST/YD): 6/200, 8/140, 10/120 | Braid (LB/YDS): 10/150, 15/145, 30/100 | Mono/Braid (MM/M): 0.18-290/0.20-240/0.25-160 Left hand, Right hand ~ 300 $
21 Sustain FJ C3000 3000 8+1 5.3:1 210.00 GM / 7.40 OZ 9.00 KG / 20.00 LB 78.00 CM / 31.00 IN Mono (#TEST/YD): 6/230, 8/170, 10/140 | Braid (LB/YDS): 10/200, 20/140, 40/105 | Mono/Braid (MM/M): 0.25-210/0.30-130/0.35-100 Left hand, Right hand ~ 300 $
21 Sustain FJ C3000HG 3000 8+1 6.0:1 210.00 GM / 7.40 OZ 9.00 KG / 20.00 LB 89.00 CM / 35.00 IN Mono (#TEST/YD): 6/230, 8/170, 10/140 | Braid (LB/YDS): 10/200, 20/140, 40/105 | Mono/Braid (MM/M): 0.25-210/0.30-130/0.35-100 Left hand, Right hand ~ 300 $
21 Sustain FJ C3000XG 3000 8+1 6.4:1 210.00 GM / 7.40 OZ 9.00 KG / 20.00 LB 94.00 CM / 37.00 IN Mono (#TEST/YD): 6/230, 8/170, 10/140 | Braid (LB/YDS): 10/200, 20/140, 40/105 | Mono/Braid (MM/M): 0.25-210/0.30-130/0.35-100 Left hand, Right hand ~ 300 $
21 Sustain FJ 4000 4000 8+1 5.3:1 275.00 GM / 9.70 OZ 11.00 KG / 24.00 LB 87.00 CM / 34.00 IN Mono (#TEST/YD): 8/240, 10/200, 12/160 | Braid (LB/YDS): 15/230, 30/180, 50/120 | Mono/Braid (MM/M): 0.25-260/0.30-180/0.35-130 Left hand, Right hand ~ 310 $
21 Sustain FJ 4000HG 4000 8+1 5.8:1 275.00 GM / 9.70 OZ 11.00 KG / 24.00 LB 95.00 CM / 37.00 IN Mono (#TEST/YD): 8/240, 10/200, 12/160 | Braid (LB/YDS): 15/230, 30/180, 50/120 | Mono/Braid (MM/M): 0.25-260/0.30-180/0.35-130 Left hand, Right hand ~ 310 $
21 Sustain FJ 4000XG 4000 8+1 6.2:1 280.00 GM / 9.90 OZ 11.00 KG / 24.00 LB 101.00 CM / 40.00 IN Mono (#TEST/YD): 8/240, 10/200, 12/160 | Braid (LB/YDS): 15/230, 30/180, 50/120 | Mono/Braid (MM/M): 0.25-260/0.30-180/0.35-130 Left hand, Right hand ~ 310 $
21 Sustain FJ C5000XG 5000 8+1 6.2:1 280.00 GM / 9.90 OZ 11.00 KG / 24.00 LB 101.00 CM / 40.00 IN Mono (#TEST/YD): 10/240, 12/195, 14/165 | Braid (LB/YDS): 20/260, 30/235, 40/185 | Mono/Braid (MM/M): 0.30-240/0.35-175/0.40-120 Left hand, Right hand ~ 310 $
